1-12

Chapter 1: Product introduction

1.7 Connectors

1.7.1 Rear panel connectors

LAN port

SPEED

LED

ACT/LINK

LED

Activity/Link LED Speed LED

Status Description Status Description

Off No link OFF 10Mbpsconnection

Orange Linked ORANGE 100Mbpsconnection

Orange

(Blinking)

Dataactivity GREEN 1Gbpsconnection

Orange

(Blinking

thensteady)

Readytowake

upfromS5

mode

14 12

5 6 7 8

910

1. PS/2 keyboard/mouse combo port.ThisportisforaPS/2keyboardormouse.

2. Optical S/PDIF Out port.Thisportconnectsanexternalaudiooutputdeviceviaan

opticalS/PDIFcable.

3. Video Graphics Adapter (VGA) port. This15-pinportisforaVGAmonitororother

VGA-compatibledevices.

4. LAN (RJ-45) port.ThisportallowsGigabitconnectiontoaLocalAreaNetwork(LAN)

through a network hub.

LAN port LED indications

5. Center / Subwoofer port (orange).Thisportconnectsthecenter/subwooferspeakers.

6. Rear Speaker Out port (black).Thisportconnectstherearspeakersina4.1channel,

5.1channel,or7.1channelaudioconguration.

7. Line In port (light blue).Thisportconnectstothetape,CD,DVDplayer,orother

audio sources.

8. Line Out port (lime). Thisportconnectstoaheadphoneoraspeaker.Inthe4.1,5.1,

and7.1-channelcongurations,thefunctionofthisportbecomesFrontSpeakerOut.
