Chapter 1: Product introduction
9. TPM connector (20-1 pin TPM)
ThisconnectorsupportsaTrustedPlatformModule(TPM)system,whichcansecurely
storekeys,digitalcerticates,passwordsanddata.ATPMsystemalsohelpsenhance
networksecurity,protectsdigitalidentities,andensuresplatformintegrity.
PIN 1
TPM
SB_SUS_STAT GND +3VSB SMBSCL LAD0 +3V LAD3 PCIRST# FRAME PCICLK
RESET
GPIO
SERIRQ
SMBSDA
GND
LAD1 LAD2
PWROWN
GND
A88X-GAMER
A88X-GAMER TPM Connector
1.8 Onboard LEDs
1. Standby Power LED
ThemotherboardcomeswithastandbypowerLEDthatlightsuptoindicatethatthe
systemisON,insleepmode,orinsoft-offmode.Thisisareminderthatyoushould
shutdownthesystemandunplugthepowercablebeforeremovingorplugginginany
motherboardcomponent.TheillustrationbelowshowsthelocationoftheonboardLED.
A88X-GAMER
A88X-GAMER Onboard LED
SB_PWR
ON
Standby Power
Powered Off
OFF
