Asus B150 PRO GAMING User Manual

1-2
Chapter 1: Product introduction
Place this side
towards the rear
of the chassis
1.2.3 Motherboard layout
PCIEX16_1
CPU_LED
DRAM_LED
VGA_LED
BOOT_DEVICE_LED
PCIEX16_2
PCI1
PCI2
PCIEX1_2
PCIEX1_1
M.2(SOCKET3)
Intel
I219V
ASM
1142
ASM
1442K
USB1112
AAFP
EATXPWR
BATTERY
Super
I/O
SupremeFX LED
SupremeFX
ALC
1150
TPU
KBMS_USB78
T_SENSOR
CLRTC
CPU_OV
24.4cm(9.6in)
DDR4 DIMM_A1 (64bit, 288-pin module) DDR4 DIMM_A2 (64bit, 288-pin module) DDR4 DIMM_B1 (64bit, 288-pin module) DDR4 DIMM_B2 (64bit, 288-pin module)
SATA6G_3 SATA6G_4 SATA6G_5 SATA6G_6
SATA6G_12
LANGuard
USB3.1_EA1
USB3_56
USB3.1_EC1
LAN_USB3_34
CHA_FAN1
CHA_FAN3
CHA_FAN2
CPU_FAN
W_PUMP
30.5cm(12.0in)
LGA1151
DIGI
+VRM
COM
EATX12V
USB3_12
Intel
®
B150
TPM
ROG_EXT
128Mb
BIOS
PANEL
SB_PWR
AUDIO
USB910
VGA HDMI
asmedia
ASM1083
21 3 42
111213 10141516171819 2
2
1
5
6
7
9
8

Asus B150 PRO GAMING Specifications

General

Non-ECC	Yes
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133 MHz
Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel® Celeron®
USB 2.0 connectors	2
Number of SATA II connectors	0
Number of SATA III connectors	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
Supported storage drive interfaces	M.2, SATA III
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	128 Mbit
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Component for	PC
Motherboard chipset	Intel® B150
Audio output channels	7.1 channels
Motherboard form factor	ATX
Parallel processing technology support	2-Way CrossFireX, 4-Way CrossFireX

Weight and Dimensions

Depth	244 mm
Width	305 mm
