5.4.4 JMicron
®
RAID Conguration
The JMicron
®
Serial ATA controller allows you to congure RAID 0, RAID 1 and
JBOD sets on the external Serial ATA hard disk drives.
Before creating a RAID set
Prepare the following items:
1. Two SATA HDDs, preferably with the same model and capacity.
2. A write-enabled oppy disk (Windows XP). A write-enabled oppy disk or a
USB ash disk drive (Windows Vista)
3. Microsoft
®
Windows
®
OS installation disk (Windows XP)
4. Motherboard support DVD with JMB363 driver
Complete the following steps before you create a RAID set:
1. Install two external Serial ATA hard disk drives on your system.
2. Set the
Controller Mode
item in the BIOS to [RAID]. See section
4.5.5
Onboard Devices Conguration
for details.
3. Enter the JMB363 RAID BIOS utility to set up your RAID conguration.
4. Create a JMB363 RAID driver disk for Windows
®
OS installation. See section
5.5 Creating a RAID driver disk
for details.
5. Install the JMB363 driver after the Windows
®
OS had been installed.
Always install the JMB363 driver before creating RAID sets.
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.58 (C)Copyright 1985-2007, American Megatrends, Inc.
Onboard Device Conguration
J-Micron eSATA/PATA Controller [Enabled]
Controller Mode [IDE]
Marvell Gigabit LAN 1 [Enabled]
LAN Boot ROM [Disabled]
Marvell Gigabit LAN 2 [Enabled]
LAN Boot ROM [Disabled]
VIA Firewire 1394 [Enabled]
BIOS SETUP UTILITY
Advanced
Options
Enabled
Disabled
