4-20 Chapter 4: BIOS setup
CPU Voltage [Auto]
Allows you to select the CPU VCore voltage. The text color in the conguration
eld corresponds to the onboard CPU LED color, both of which indicate CPU
voltage condition. Refer to page 2-1 for CPU LED denition.
Conguration options: [Auto] [1.10000V] [1.10625V] [1.11250V] [1.11875V]
[1.12500V] [1.13125V] [1.13750V] [1.14375V] [1.50000V] [1.15625V] [1.16250V]
[1.16875V] [1.17500V] [1.18125V] [1.18750V] [1.19375V] [1.20000V] [1.20625V]
[1.21250V] [1.21875V] [1.22500V] [1.23125V] [1.23750V] [1.24375V] [1.25000V]
[1.25625V] [1.26250V] [1.26875V] [1.27500V] [1.28125V] [1.28750V] [1.29375V]
[1.30000V]~[1.80000V] [1.80625V] [1.81250V] [1.81875V] [1.82500V] [1.83125V]
[1.83750V] [1.84375V] [1.85000V] [1.85625V] [1.86250V] [1.86875V] [1.87500V]
[1.88125V] [1.88750V] [1.89375V] [1.90000V]
Refer to the CPU documentation before setting the CPU Vcore voltage. Setting
a high VCore voltage may damage the CPU permanently, and setting a low
VCore voltage may make the system unstable.
CPU Voltage Reference [Auto]
Conguration options: [Auto] [0.531V] [0.545V] [0.561V] [0.576V] [0.581V] [0.597V]
[0.618V] [0.635V]
Loadline Calibration [Auto]
Conguration options: [Auto] [Disabled] [Enabled]
FSB Termination Voltage [Auto]
Allows you to select the front side bus (FSB) termination voltage. The text color
in the conguration eld indicates FSB termination voltage condition. When you
set the NB LED Selection item to [FSBT Volt], the onboard northbridge LED
displays FSB termination voltage condition. Refer to page 2-2 for northbridge LED
denition.
Conguration options: [Auto] [1.20V] [1.22V] [1.24V] [1.26V] [1.28V] [1.30V]~
[1.70V] [1.72V] [1.74V] [1.76V] [1.78V] [1.80V]
Setting a high FSB termination voltage may damage the chipset and CPU.
North Bridge Voltage [Auto]
Allows you to select the northbridge voltage. The text color in the conguration eld
indicates northbridge voltage condition. When you set the NB LED Selection item
to [NB Volt], the onboard northbridge LED displays northbridge voltage condition.
Refer to page 2-2 for northbridge LED denition.
Conguration options: [Auto] [1.25V] [1.27V] [1.29V] [1.31V]~[1.97V] [1.99V]
[2.01V] [2.03V]
The following item only appears when you set the Ai Overclocking item to
[Manual] or [N.O.S.].
