Asus Eee PC 4G User Manual

Disassembly procedure
2 - 11
LCD Module
The illustrations below show how to remove and disassemble the LCD module. The
module contains LCD panel, Inverter board, LCD bezel, LCD back cover.
Disassembling LCD Module
1. Remove 8 rubber pads and screws (M2*4) on LCD front bezel.
2. Pry the four inner sides of LCD front bezel and separate it from LCD module.
3. Remove 2 screws (M2*4) on each LCD hinge and remove both hinges.
LCD MODULE
LCD MODULE
DISASSEMBLY

Asus Eee PC 4G Specifications

General

Processor family	Intel® Celeron® M
Processor frequency	0.9 GHz
Processor manufacturer	Intel
Internal memory	0.5 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
SSD capacity	4 GB
Card reader integrated	Yes
HD type	Not supported
Display diagonal	7 \
Display resolution	800 x 480 pixels
Native aspect ratio	5:4
Graphics card	GMA 900
Wireless technology	802.11 b/g
Audio system	HD Audio
Front camera resolution (numeric)	0.3 MP
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Networking features	Fast Ethernet, WLAN
Operating system installed	Linux
Product type	Netbook
Product color	White
Battery capacity	5200 mAh
Battery life (max)	3.5 h
Number of battery cells	4
Pointing device	Touchpad

Weight and Dimensions

Depth	165 mm
Width	225 mm
Height	35 mm
Weight	920 g
