Asus H81M-CT User Manual

ASUS H81M-CT
2-21
Power On By PCIE/PCI [Disabled]
[Disabled] Disables the PCIE/PCI devices to generate a wake‑on‑LAN feature of the
Intel
®
/Realtek LAN device.
[Enabled] Enables the PCIE/PCI devices to generate a wake‑on‑LAN feature of the
Intel
®
/Realtek LAN device.
Power On By RTC [Disabled]
[Disabled] Disables RTC to generate a wake event.
[Enabled] When set to [Enabled], the items RTC Alarm Date (Days) and Hour/
Minute/Second will become user‑congurable with set values.
Power On By RTC [S1 only (CPU Stop Clock)]
Select the ACPI sleep state the system will enter when the suspend button is pressed.
Conguration options: [S1 only (CPU Stop Clock)] [S3 only (Suspend to RAM)]
Support G3 Wakeup [Disabled]
Allows you to enable or disable the G3 wakeup support. Conguration options: [Enabled]
[Disabled]
2.6.9 Network Stack Configuration
Network Stack [Disabled]
This item allows user to disable or enable the UEFI network stack. Conguration options:
[Disabled] [Enabled]
The following two items appear only when you set the previous item to [Enabled].
Ipv4 PXE Support [Enabled]
This item allows user to disable or enable the Ipv4 PXE Boot support. Conguration options:
[Disabled] [Enabled]
Ipv6 PXE Support [Enabled]
This item allows user to disable or enable the Ipv6 PXE Boot support. Conguration options:
[Disabled] [Enabled]

Asus H81M-CT Specifications

General

Form Factor	Micro ATX
Chipset	Intel H81
Socket	LGA 1150
Memory Slots	2
Maximum Memory	16GB
Memory Type	DDR3
PCIe x16 Slots	1
PCIe x1 Slots	2
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
USB Ports	2 x USB 3.0, 8 x USB 2.0
LAN	Realtek 8111G
Video Outputs	VGA, DVI
