Asus H81M-K User Manual

vi
(continued on the next page)
H81M-K specications summary
CPU LGA1150 socket for Intel
®
4th Generation Core
TM
i7/ i5 / i3, Pentium
®
and
Celeron
®
Processors
Supports 22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H81 Express Chipset
Memory 2 x DIMMs, max. 16GB DDR3 1600/1333/1066MHz, non-ECC, unbuffered
memory modules
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual
CPUs. Please refer to Memory QVL for details.
** Refer to
www.asus.com for the latest Memory QVL (Qualied Vendors List).
*** Due to Intel
®
chipset limitations, DDR3 1600MHz and higher memory modules
on XMP mode will run at the maximum transfer rate of DDR3 1600MHz.
Graphics Integrated Graphics Processor - Intel
®
HD Graphics support
Multi-VGA output support: DVI-D, RGB port
- Supports DVI-D with max. resolution up to 1920 x1200@60Hz
- Supports RGB with max. resolution 1920x1200@60Hz
- Maximum shared memory of 1024MB
Expansion slots 1 x PCI Express x16 slot (at x16 mode, yellow)
2 x PCI Express x1 slots
Storage
Intel
®
H81 Express Chipset:
- 2 x Serial ATA 6.0 Gb/s connectors (yellow)
- 2 x Serial ATA 3.0 Gb/s connectors (dark brown)
- Supports Intel
®
Rapid Start Technology* and Intel
®
Smart Connect
Technology**
* Due to the limitation of the Intel
®
H81 chipset, Intel
®
Rapid Start Technology can
be congured only from the BIOS Setup program.
** These functions will work depending on the CPU installed.
Package contents
Check your motherboard package for the following items.
Motherboard ASUS H81M-K motherboard
Cables 2 x Serial ATA 6.0 Gb/s cables
Accessories 1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.

Asus H81M-K Specifications

General

Non-ECC	Yes
Flash memory	64 MB
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	4
Number of EATX power connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Supported storage drive interfaces	SATA
USB 2.0 ports quantity	2
LAN controller	Realtek 8111G
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC887
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H81
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Maximum resolution	1920 x 1200 pixels
Maximum graphics card memory	1024 MB
Parallel processing technology support	Not supported
BIOS type	UEFI AMI

Weight and Dimensions

Depth	175 mm
Width	226 mm
