Asus H81M-K User Manual

vii
H81M-K specications summary
LAN
Realtek
®
RTL8111G Gigabit LAN Controller
Audio Realtek
®
ALC887 8-Channel High Denition Audio CODEC
- Supports Jack-Detection and Front Panel Jack-Retasking
* Use a chassis with HD audio module in the front panel to support an
8-channel audio output
USB
Intel
®
H81 Express Chipset
- 2 x USB 3.0/2.0 ports at rear panel (blue)*
- 6 x USB 2.0/1.1 ports (4 ports at mid-board, 2 ports at the rear panel)
* Supports ASUS USB 3.0 Boost
ASUS unique
features
ASUS Exclusive Features:
- ASUS EPU
- ASUS UEFI BIOS EZ Mode featuring a friendly graphical user interface
- ASUS USB 3.0 Boost
- ASUS AI Charger
- ASUS GPU Boost
- ASUS AI Suite 3
- ASUS Anti-surge Protection
- ASUS ESD
ASUS Quiet Thermal Solution
- ASUS Fanless Design: Stylish Heatsink solution
- ASUS Fan Xpert
ASUS Q-Design
- ASUS Q-Slot
ASUS EZ DIY:
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
Back Panel I/O
ports
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
2 x USB 3.0/2.0 ports
2 x USB 2.0/1.1 ports
1 x DVI port
1 x D-Sub port
1 x LAN (RJ-45) port
3 x Audio jacks support 8-channel audio output
Internal
I/O connectors/
buttons/switches
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports
2 x SATA 6.0Gb/s connectors
2 x SATA 3.0Gb/s connectors
1 x CPU fan connector
1 x Chassis fan connector
1 x Front panel audio connector
1 x S/PDIF Out connector
1 x 24-pin EATX power connector
1 x 4-pin EATX 12V power connector
1 x Speaker connector
1 x System panel connector
1 x CLRTC jumper
(continued on the next page)

Asus H81M-K Specifications

General

Non-ECC	Yes
Flash memory	64 MB
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	4
Number of EATX power connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Supported storage drive interfaces	SATA
USB 2.0 ports quantity	2
LAN controller	Realtek 8111G
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC887
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H81
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Maximum resolution	1920 x 1200 pixels
Maximum graphics card memory	1024 MB
Parallel processing technology support	Not supported
BIOS type	UEFI AMI

Weight and Dimensions

Depth	175 mm
Width	226 mm
