Asus P320 User Manual

56
6. After you nish the wizard, ActiveSync automatically synchronizes your device. You can disconnect
the device after the synchronization is complete.
NOTES:
• When connected, your device is automatically synchronized with your computer. ActiveSync synchronizes
everytime you make a change on either the device or computer.
• You cannot use WLAN to synchronize database.
• Refer to your Windows
®
Mobile Help, for more information about ActiveSync synchronization.
• Wireless connection may require separately purchased equipment (eg. Wireless router or Access Point).
Synchronizing via mini-USB
You can connect to your device using the bundled mini-USB cable to synchronize to your computer.
To synchronize your device via mini-USB:
1. After installing ActiveSync to your computer, connect the mini-USB plug to the mini-USB connector
at the bottom of the device.
2. Connect the other end of the USB cable to your computer. Upon connection, ActiveSync
automatically synchronizes your device.

Asus P320 Specifications

General

Processor	TI OMAP 850 200MHz
Operating System	Microsoft® Windows Mobile™ 6.1 Professional
Memory	128 MB Flash ROM 64 MB DDR RAM
Expansion slot	MicroSD card slot
Display	2.6-inch, 240 x 320 TFT Touchscreen Liquid Crystal Display (LCD) with 65, 536 color and LED backlighting
Frequency band	Quadband GSM (850/900/1800/1900 MHz) Integrated GSM/GPRS/EDGE and GPS with internal antenna
GPS	Built-in SiRF Star III chipset
GPRS	Class B, Multi-slot class 10
Camera	2.0 megapixel Auto Focus camera
Connectivity	Bluetooth : V2.0+EDR USB : USB Client 1.1 WLAN : IEEE 802.11b+g
Battery capacity	1100 mAh Lithium Ion (Manufacturer: Welldone; Model: SBP-17 LION HARD-PACK)
Talk time*	4 hrs (*vary with different networking environment and scenario)
Standby time*	200 hrs (*vary with different networking environment and scenario)
Audio	Built-in microphone and stereo output speaker

Weight and Dimensions

Weight	105g (with battery)
Dimension	99 mm (L) x 54.5 mm (W) x 13.35 mm (T)
