58
Volume Recommended setup
High
Select a shorter interval in the
Peak times list.
Low
Select As items arrive option
or a longer interval in the
Offpeak times list.
While roaming
Check Use above settings
while roaming.
Sending messages
Check Send/Receive when I
click Send.
Synchronizing with an Exchange Server
To synchronize your device with Exchange Server:
1. From the ActiveSync menu, tap Menu > Add Server Source.
2. Enter your email address, then tap Next. If you prefer the device to detect the Exchange Server
Settings automatically, tap the check box Attempt to detect Exchange Server Settings
automatically.
3. In the Server Address eld, enter the name of the server running Exchange Server then tap Next. If
necessary, tap the check box This server requires an encrypted (SSL) connection.
4. Enter your name, password, and domain then tap Next.
5. Tap the check boxes to select the data items that you want to synchronize with Exchange Server. To
change the available synchronization settings, select a data item then tap Settings. Tap Finish when
done.
6. Start the sync process.
Setting the synchronization schedule
To set the synchronization with Exchange
Server:
1. From the ActiveSync screen, tap Menu
> Schedule.
2. Refer to the table for input details.

Table of Contents

Other manuals for Asus P320

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus P320 and is the answer not in the manual?

Asus P320 Specifications

General IconGeneral
ProcessorTI OMAP 850 200MHz
Operating SystemMicrosoft® Windows Mobile™ 6.1 Professional
Memory128 MB Flash ROM 64 MB DDR RAM
Expansion slotMicroSD card slot
Display2.6-inch, 240 x 320 TFT Touchscreen Liquid Crystal Display (LCD) with 65, 536 color and LED backlighting
Frequency bandQuadband GSM (850/900/1800/1900 MHz) Integrated GSM/GPRS/EDGE and GPS with internal antenna
GPSBuilt-in SiRF Star III chipset
GPRSClass B, Multi-slot class 10
Camera2.0 megapixel Auto Focus camera
ConnectivityBluetooth : V2.0+EDR USB : USB Client 1.1 WLAN : IEEE 802.11b+g
Battery capacity1100 mAh Lithium Ion (Manufacturer: Welldone; Model: SBP-17 LION HARD-PACK)
Talk time*4 hrs (*vary with different networking environment and scenario)
Standby time*200 hrs (*vary with different networking environment and scenario)
AudioBuilt-in microphone and stereo output speaker
Weight and Dimensions IconWeight and Dimensions
Weight105g (with battery)
Dimension99 mm (L) x 54.5 mm (W) x 13.35 mm (T)
