Asus P526 User Manual

16
Installing the SIM card and battery
Before you can make a phone call using your P526, you need to install a Subscriber Identity
Module (SIM) card. A SIM card contains your phone number, subscriber details, phonebook,
and additional phone memory.
Your P526 comes with a rechargeable Lithium-Ion battery.
New batteries come partially discharged and should be fully charged before using them. They
generally do not reach their rated capacity until they have been charged and discharged at
least four (4) times. We recommend that new batteries be charged overnight even though
they may indicate that the charge is complete after a few hours. Sometimes charging may
stop during the initial charge and it is necessary to remove the battery for approximately
fteen (15) minutes and then put it back on charge.
Getting your device ready
1. Remove the battery compartment cover.
NOTE:
When turned on, the device automatically turns off
after you open the battery compartment to prevent
data loss.
CAUTION:
Use only an ASUS qualied battery.
To install a SIM card and battery:

Asus P526 Specifications

General

Processor	TI OMAP 850
Operating System	Microsoft® Windows Mobile™ 6
Memory	128 MB NAND Flash ROM 64 MB SDRAM
Expansion slot	MicroSD card slot
Display	2.6-inch, 320 x 240 TFT Touchscreen Liquid Crystal Display (LCD) with 65, 536 color and LED back-lighting
Frequency band	Quad-band GSM (850/900/1800/1900 MHz) Integrated GSM/GPRS/EDGE and GPS with internal antenna
GPS	Built-in SiRF star III chipset
GPRS	Class B, Multislot class 10
Connectivity	Bluetooth : V1.2 USB : USB Client 1.1
Camera	2.0 mega-pixel fixed focus camera
Battery capacity	1300 mAh Lithium Ion
Talk time*	4 hrs (*vary with different networking environment and scenario)
Standby time*	150 hrs (*vary with different networking environment and scenario)
Audio	2.5 mm audio port Built-in microphone and stereo output speaker

Weight and Dimensions

Weight	115g (with battery)
Dimension	110 x 58 x 15.4 mm
