Asus P8B75-M LX User Manual

ASUS P8B75-M LX 1-1
Chapter 1
Product introduction
Motherboard ASUS P8B75-M LX motherboard
Cables 1 x Serial ATA 6.0Gb/s cable
1 x Serial ATA 3.0Gb/s cable
Accessories 1 x I/O shield
Application DVD ASUS motherboard support DVD
Documentation User Manual
If any of the above items is damaged or missing, contact your retailer.
1.3 Special features
1.3.1 Product highlights
LGA1155 socket for Intel
®
3rd/2nd Generation Core™ i7 /
Core™ i5 / Core™ i3 processors
This motherboard supports the Intel
®
3rd/2nd generation Core™ i7 /
Core™ i5 / Core™ i3 processors in the LGA1155 package, with memory
and PCI Express controllers integrated to support dual-channel (4
DIMMs) DDR3 memory and 16 PCI Express 3.0 lanes. This provides
great graphics performance. Intel
®
3rd/2nd generation Core™ i7 / Core™
i5 / Core™ i3 processors are among the most powerful and energy
efcient CPUs in the world.
1.1 Welcome!
Thank you for buying an ASUS
®
P8B75-M LX motherboard!
The motherboard delivers a host of new features and latest technologies, making it another
standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it, check the items in
your package with the list below.
1.2 Package contents
Check your motherboard package for the following items.

Asus P8B75-M LX Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2000, 2133, 2200 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel® Celeron® G
Number of SATA II connectors	5
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	4
Audio chip	VIA VT1708S
Component for	PC
Power source type	ATX
Motherboard chipset	Intel B75
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II, SATA III
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1024 MB
Parallel processing technology support	LucidLogix Virtu
PCI Express slots version	2.0, 3.0
Cables included	SATA
LAN controller	Realtek RTL8111F
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	128 Mbit

Weight and Dimensions

Depth	198 mm
Width	244 mm
