2-14 ASUS P8Z68-V LX
2.4.1 Ai Overclock Tuner [Auto]
Allows you to select the CPU overclocking options to achieve the desired CPU internal
frequency. Select any of these preset overclocking conguration options:
[Auto] Loads the optimal settings for the system.
[Manual] Allows you to individually set overclocking parameters.
BCLK/PEG Frequency [XXX]
Appears when you set the Ai Overclock Tuner item to [Manual] and allows you to adjust the
CPU and VGA frequency to enhance the system performance. Use the <+> and <-> keys to
adjust the value. You can also key in the desired value using the numeric keypad. The values
range from 80MHz to 300MHz.
2.4.2 Turbo Ratio [By All Cores]
Allows you to manually adjust the Trubo CPU ratio.
[Auto] All Turbo ratio are set by Intel CPU default settings.
[By ALL Cores (Can Adjust in OS)] All numbers of active cores will be set to one single
Turbo ratio in OS.
[By Per Core (Cannot Adjust in OS)] All numbers of active cores can be set to an individual
Turbo ratio in BIOS.
By ALL Cores (Can Adjust in OS) [XX]
This item appears only when you set the Turbo Ratio item to [By ALL Cores (Can
Adjust in OS)]. Use the <+> and <-> keys to adjust the value.
1-/2-/3-/4-Core Ratio Limit [XX]
This item appears only when you set the Turbo Ratio item to [By Per Core
(Cannot Adjust in OS)]. Use the <+> and <-> keys to adjust the value.
2.4.3 Internal PLL Overvoltage [Auto]
Allows you to set the Internal PLL Overvoltage. Conguration options: [Auto] [Enabled]
[Disabled]
2.4.4 Memory Frequency [Auto]
Allows you to set the memory operating frequency. Conguration options: [Auto]
[DDR3-800MHz] [DDR3-1066MHz] [DDR3-1333MHz] [DDR3-1600MHz] [DDR3-1866MHz]
[DDR3-2133MHz] [DDR3-2400MHz]
Selecting a very high memory frequency may cause the system to become unstable! If this
happens, revert to the default setting.
2.4.5 iGPU Max. Frequency [Auto]
Allows you to set the maximum frequency for the internal GPU. Use the <+> and <-> keys to
adjust the value. You can also key in the desired value using the numeric keypad. The values
range from 1100MHz to 3000MHz.

Asus P8Z68-V LX Specifications

General

Form Factor	ATX
Chipset	Intel Z68
Socket	LGA 1155
Max Memory	32GB
Memory Type	DDR3
Memory Standard	DDR3 2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066
PCI Express x16	1
PCI Express x1	2
PCI Slots	3
SATA 6Gb/s	2
SATA 3Gb/s	4
USB 3.0 Ports	2
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
LAN	Realtek 8111E, 1 x Gigabit LAN Controller(s)
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4
