ASUS P9X79 PRO 3-41
Chapter 3
3.8.2 ASUS DRAM SPD Information
This menu showed the DIMM slot related informatons.
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
DIMM Slot number
Back Tool\ ASUS DRAM Information\ ASUS SPD Information >
UEFI BIOS Utility - Advanced Mode
DIMM Slot # DIMM_B1
Manufacure Samsung
Module Size 1024 MBytes
Maximum Bandwidth 1333Mhz
Part Number M391B2873DZ1-CH9
Serial Number 06036a40
Product Week/Year 15/2008
SPD Ext.
JEDEC ID JEDEC
Frequency(Mhz) 1333
Voltage(V) 1.500
CAS# Latency(tCL) 9
RAS# to CAS#(tRCD) 9
RAS# Precharge(tRP) 9
tRAS 24
tRC 33
tWR 10
tRRD 4
tRFC 74
tWTR 5
tRTP 5
tFAW 20
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
UEFI BIOS Utility - Advanced Mode
Back Tool\ ASUS DRAM Information\ ASUS DRAM Information >
> DIMM_A1 N/A
> DIMM_A2 N/A
> DIMM_B1 N/A
> DIMM_B2 OK
> DIMM_C1 N/A
> DIMM_C2 N/A
> DIMM_D1 N/A
> DIMM_D2 N/A

Asus P9X79 PRO Specifications

General

Non-ECC	Yes
Memory channels	Quad-channel
Number of memory slots	8
Supported memory types	DDR3-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133, 2400 MHz
Processor socket	LGA 2011 (Socket R)
Processor manufacturer	Intel
Compatible processor series	Intel Core i7, Intel Core i7 Extreme Edition
USB 2.0 connectors	3
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
BIOS type	UEFI
ACPI version	2.0a
BIOS memory size	64 Mbit
eSATA ports quantity	2
USB 2.0 ports quantity	6
Audio chip	Realtek ALC898
Component for	PC
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
On-board graphics card	No
Parallel processing technology support	3-Way SLI, Quad-GPU CrossFireX
LAN controller	Intel® 82579V
Bluetooth version	2.1+EDR
Ethernet interface type	Gigabit Ethernet
Controller interface type	SATA 6Gb/s
Controller 2nd interface type	SATA 3Gb/s

Weight and Dimensions

Depth	244 mm
Width	305 mm
