12
Clock Displays system time.
Fan speed gauge Displays the duty cycles of CPU fans 1 and 2,
Chassis fans 1, 2, and 3.
Mode/Status indicator Displays the current status of ROG Front
Base. The information displayed vary
depending on the mode of the device.
Temperature gauge Displays the CPU and motherboard (MB)
temperature.
CPU Level Up OC icon Appears when the CPU Level Up OC button
is pressed.
Audio Equalization bar Shows the current audio EQ mode in use.
CPU Frequency gauge Displays the current CPU Frequency or speed.
GHz
The ROG Front Base LCD panel
The 4-inch LCD of the ROG Front Base provides at-a-glance view of all the
information about your system whether your system is on or powered off.
To turn off/on the LCD, press the LCD panel power button on the front panel.
The LCD panel displays the following information:
NOTES:
The following shows the cycle when your press the CPU Level Up OC button
repeatedly:
(Normal mode)
The overclocking values of LV1 and LV2 depend on the CPU type or
motherboard installed.
Restore the system to its default settings if the system becomes unstable. For
more details, refer to the BIOS section of your motherboard’s user manual.
