Asus RT-N12 C1 User Manual

12
RT-N12 C1 Chapter 2: Setting up the hardware
Modem
RT-N12 C1
Client
ROUTER
AP
REPEATER
2. Connect your devices.
Setting up the wireless router in Router mode
In the Router mode, the wireless router connects to the Internet via PPPoE,
Automatic IP, PPTP, L2TP, or Static IP, and provides you with wireless radio
signals. The NAT, rewall, and IP sharing services for LAN clients are enabled.
To set up the wireless router in Router mode:
1. Choose the Router mode.
Router AP
Repeater
RT-N12 C1
ROUTER
AP
REPEATER
Note: We recommend that you use an Ethernet cable (wired connection) to connect your
computer to the wireless router for initial conguration to avoid possible setup problems due to
wireless uncertainty.

Asus RT-N12 C1 Specifications

General

Frequency Band	2.4 GHz
Data Rate	Up to 300 Mbps
Antenna	2 x 5 dBi external antennas
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
Wireless Standard	IEEE 802.11n
Security	WEP, WPA, WPA2
Firewall	SPI
Operating Mode	Router, Repeater, Access Point
Dimensions	179 x 128 x 28 mm (without antenna)
