Asus RT-N12 C1 User Manual

27
Chapter 4: Conguring via the web GUI RT-N12 C1
4
Conguring via
the web GUI
Conguring via the web GUI
The router’s web graphics user interface (web GUI) allows you to congure these
features: Network Map and EZQoS Bandwidth Management.
To access the web GUI:
1. Launch a web browser, then key in the router’s IP address. The login page of
the router’s web GUI appears.
2. On the login page, key in the default user name (admin) and password
(admin).
Note:
• In the Router mode, the router’s IP address is 192.168.1.1.
• In the Repeater and AP modes, use Device Discovery included in the support CD to nd the
router’s IP address.

Asus RT-N12 C1 Specifications

General

Frequency Band	2.4 GHz
Data Rate	Up to 300 Mbps
Antenna	2 x 5 dBi external antennas
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
Wireless Standard	IEEE 802.11n
Security	WEP, WPA, WPA2
Firewall	SPI
Operating Mode	Router, Repeater, Access Point
Dimensions	179 x 128 x 28 mm (without antenna)
