Asus RT-N12 C1 User Manual

37
Chapter 5: Installing the utilities RT-N12 C1
Device Discovery
Device Discovery is an ASUS WLAN utility that detects an ASUS wireless router
and enables you to congure the device.
To launch the Device Discovery utility:
From your computer’s desktop, click Start > All Programs > ASUS Utility >
RT-N12 C1 Wireless Router > Device Discovery.
• Click Congure to access the web GUI and congure the wireless router.
• Click Search to search for ASUS wireless routers within range.
• Click Exit to exit the application.

Asus RT-N12 C1 Specifications

General

Frequency Band	2.4 GHz
Data Rate	Up to 300 Mbps
Antenna	2 x 5 dBi external antennas
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
Wireless Standard	IEEE 802.11n
Security	WEP, WPA, WPA2
Firewall	SPI
Operating Mode	Router, Repeater, Access Point
Dimensions	179 x 128 x 28 mm (without antenna)
