Chapter 4: Conguring via the web GUI RT-N12 C1
Using the Network Map
Network Map allows you to view the status and congure the connection settings
of the Internet, system, and clients in your network. It enables you to quickly set up
your Wide Area Network (WAN) using the Quick Internet Setup (QIS) feature.
To view the status or congure the settings, click any of these icons displayed on
the main page:
Icon Description
Internet status
Click this icon to display information on the Internet
connection status, WAN IP address, DNS, connection type,
and gateway address. From the Internet status screen, use
the Quick Internet Setup (QIS) feature to quickly set up your
network.
System status
Click this icon to display information on the SSID,
authentication and encryption methods, LAN IP, MAC
address, or turn the wireless radio on/off. Enable the WPS
mode from the System status screen.
Client status
Click this icon to display information about the clients or
computers in the network, and allows you to block/unblock
a client.

Asus RT-N12 C1 Specifications

General

Frequency Band	2.4 GHz
Data Rate	Up to 300 Mbps
Antenna	2 x 5 dBi external antennas
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
Wireless Standard	IEEE 802.11n
Security	WEP, WPA, WPA2
Firewall	SPI
Operating Mode	Router, Repeater, Access Point
Dimensions	179 x 128 x 28 mm (without antenna)
