Asus RT-N12 User Manual

15
Chapter 2: Setting up the hardware RT-N12
Setting up the wireless router in Repeater mode
In the Repeater mode, the wireless router extends your wireless network coverage
and provides you with higher quality wireless radio signal. The NAT, rewall, and IP
sharing services are disabled.
To set up the wireless router in Repeater mode:
1. Choose the Repeater mode.
Router AP
Repeater
RT-N12
2. Connect your devices.
RT-N12
Client
Modem
Wireless Router
Note: We recommend that you use an Ethernet cable (wired connection) to connect your
computer to the wireless router for initial conguration to avoid possible setup problems due to
wireless uncertainty.

Asus RT-N12 Specifications

General

Frequency band	2.4 - 2.5 GHz
Channels quantity	13 channels
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Wireless standard	IEEE 802.11b, IEEE 802.11g, IEEE802.11n, IEEE 802.11d, IEEE 802.3
Supported data transfer rates	6, 9, 12, 18, 24, 36, 48, 54Mbps / 1, 2, 5.5, 11Mbps
Supported network protocols	B
Ethernet LAN (RJ-45) ports	5
Security algorithms	TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK
Bundled software	Device Discovery EZSetup EZ UI
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power requirements	100-240V, 50/60Hz

Weight and Dimensions

Weight	300 g
Dimensions (WxDxH)	119 x 179 x 37 mm
