Asus RT-N12 User Manual

32
RT-N12 Chapter 4: Conguring via the web GUI
Upgrading the rmware
Note: Download the latest rmware from the ASUS website at http://www.asus.com.
To upgrade the rmware:
1. Click Advanced Setting from the navigation menu at the left side of your
screen.
2. Under the Administration menu, click Firmware Upgrade.
3. In the New Firmware File eld, click Browse to locate the new rmware on your
computer.
4. Click Upload. The uploading process takes about three minutes.
Note: If the upgrade process fails, use the Firmware Restoration utility to restore the system. For
details on this utility, refer to the section Firmware Restoration in Chapter 5 of this user manual.

Asus RT-N12 Specifications

General

Frequency band	2.4 - 2.5 GHz
Channels quantity	13 channels
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Wireless standard	IEEE 802.11b, IEEE 802.11g, IEEE802.11n, IEEE 802.11d, IEEE 802.3
Supported data transfer rates	6, 9, 12, 18, 24, 36, 48, 54Mbps / 1, 2, 5.5, 11Mbps
Supported network protocols	B
Ethernet LAN (RJ-45) ports	5
Security algorithms	TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK
Bundled software	Device Discovery EZSetup EZ UI
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power requirements	100-240V, 50/60Hz

Weight and Dimensions

Weight	300 g
Dimensions (WxDxH)	119 x 179 x 37 mm
