Asus RT-N12 User Manual

29
Chapter 4: Conguring via the web GUI RT-N12
Using the Network Map
Network Map allows you to view the status and congure the connection settings
of the Internet, system, and clients in your network. It enables you to quickly set up
your Wide Area Network (WAN) using the Quick Internet Setup (QIS) feature, or to
quickly set up your Local Area Network (LAN) using the WPS Wizard.
Note: For more details on the WPS Wizard, refer to the section WPS Wizard in Chapter 5 of this
user manual.
To view the status or congure the settings, click any of these icons displayed on
the main page:
Icon Description
Internet status
Click this icon to display information on the Internet
connection status, WAN IP address, DNS, connection type,
and gateway address. From the Internet status screen, use
the Quick Internet Setup (QIS) feature to quickly set up your
network.
System status
Click this icon to display information on the SSID,
authentication and encryption methods, LAN IP, MAC
address, or turn the wireless radio on/off. Enable the WPS
mode from the System status screen.
Client status
Click this icon to display information about the clients or
computers in the network, and allows you to block/unblock
a client.

Asus RT-N12 Specifications

General

Frequency band	2.4 - 2.5 GHz
Channels quantity	13 channels
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Wireless standard	IEEE 802.11b, IEEE 802.11g, IEEE802.11n, IEEE 802.11d, IEEE 802.3
Supported data transfer rates	6, 9, 12, 18, 24, 36, 48, 54Mbps / 1, 2, 5.5, 11Mbps
Supported network protocols	B
Ethernet LAN (RJ-45) ports	5
Security algorithms	TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK
Bundled software	Device Discovery EZSetup EZ UI
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power requirements	100-240V, 50/60Hz

Weight and Dimensions

Weight	300 g
Dimensions (WxDxH)	119 x 179 x 37 mm
