Chapter 3: Network Configuration using the web GUIRT-N14U
You first need to create user accounts to allow other network
clients to access the USB device. For more details, refer to the
section Using AiDisk for File Sharing in this user manual.
To monitor your USB device:
1. On the Network Map screen, select the USB Disk Status icon to
display information about your USB device.
The wireless router works with most USB HDDs/Flash disks (up
to 2TB size) and supports read-write access for FAT16, FAT32,
EXT2, EXT3, and NTFS formatted storage.
To safely remove your USB device:
1. Click the USB icon on the upper-right corner. Click Eject USB disk.
To avoid data loss or damage to the USB storage device, always
eject your USB device before disconnecting it from the USB
port.

Asus RT-N14U Specifications

General

VPN support	IPSec Pass-Throuth\\r PPTP Pass-Through\\r L2TP Pass-Through
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
USB version	2.0
Input current	1 A
Rack mounting	-
Frequency band	2.4 GHz
Frequency range	2.4 - 2.4835 GHz
USB ports quantity	1
Minimum system requirements	Windows® 8 , 32bit/64bit\\r Windows® 7 , 32bit/64bit\\r Windows® Vista , 32bit/64bit\\r Windows® XP , 32bit/64bit
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300 Mbit/s
Ethernet LAN (RJ-45) ports	5
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
LED indicators	LAN, Power, USB, WLAN

Weight and Dimensions

Depth	145 mm
Width	187 mm
Height	77 mm
Weight	260 g
