53
Chapter 5: Troubleshooting RT-N14U
Troubleshooting
I cannot access the router GUI for conguring the router.
Delete the cookies and temporary files in your web browser. To
do this in Internet Explorer 8, follow these steps:
1. Launch your web browser, then click
Tools > Internet
Options.
2. On the General tab, click
Delete under Browsing history.
3. Tick
Temporary Internet Files and Cookies. Click Delete.
The commands for deleting cookies and files vary with the web
browser.
Disable the proxy server settings, cancel the dial-up connection,
and set the TCP/IP settings to obtain IP addresses automatically.
For more details, refer to the section Before you proceed in
this user manual.
The client cannot establish a wireless connection with the
router.
Out of Range:
Place the router closer to the wireless client.
Change the channel settings.
Authentication:
Use a wired connection to connect to the router.
Check the wireless security settings.
Press the Reset button at the rear panel for more than five
seconds.
5
Troubleshooting

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus RT-N14U and is the answer not in the manual?

Asus RT-N14U Specifications

General IconGeneral
VPN supportIPSec Pass-Throuth\\r PPTP Pass-Through\\r L2TP Pass-Through
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)300 Mbit/s
USB version2.0
Input current1 A
Rack mounting-
Frequency band2.4 GHz
Frequency range2.4 - 2.4835 GHz
USB ports quantity1
Minimum system requirementsWindows® 8 , 32bit/64bit\\r Windows® 7 , 32bit/64bit\\r Windows® Vista , 32bit/64bit\\r Windows® XP , 32bit/64bit
WLAN data transfer rates supported1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300 Mbit/s
Ethernet LAN (RJ-45) ports5
Security algorithms128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
AC input voltage110 - 240 V
AC input frequency50 - 60 Hz
LED indicatorsLAN, Power, USB, WLAN
Weight and Dimensions IconWeight and Dimensions
Depth145 mm
Width187 mm
Height77 mm
Weight260 g
