Chapter 3: General Instruction
3.5 Supported Operating Modes
Mode Resolution
Horizontal
Frequency (KHz)
Vertical
Frequency (Hz)
Pixel (MHz)
HDMI-PC
DOS 720 x 400 31.469 70.08 28.32
VESA
640 x 480 31.469 59.94 25.17
800 x 600 37.879 60.31 40.00
1024 x 768 48.363 60.00 65.00
1360 x 768 47.712 60.015 85.50
1280 x 1024 63.981 60.020 108.00
1920 x 1080 67.5 60 148.5
HDMI-DTV
SDTV 480P 720 x 480 31.469 59.94 27.00
SDTV 576P 720 x 576 31.25 50 27.00
HDTV 720P
1280 x 720 37.50 50.00 74.25
1280 x 720 44.96 59.94 74.176
HDTV 1080I
1920 x 1080 33.75 60.00 74.25
1920 x 1080 28.125 50.00 74.25
HDTV 1080P
1920 x 1080 67.500 60 148.50
1920 x 1080 56.250 50 148.50
1920 x 1080 27.000 24.000 74.25
1920 x 1080 26.97 23.976 74.176
1920 x 1080 33.75 30.000 74.25
1920 x 1080 33.71 29.97 74.176
* Modes not listed in the table may not be supported. For optimal resolution, we recommend that
you choose a mode listed in the table above.
