1.3 Systemspecications
The ASUS TS100-E10-PI4 is a pedestal server. The server supports LGA1151 Intel
®
Xeon
®
Processor E Family (Coffee Lake) and Intel
®
8th/9th Generation Core™ i3 Processors.
Model Name TS100-E10-PI4
Processor Support
1 x Socket LGA1151
Intel
®
Xeon
®
processor E-21xx/E-22xx product family
Intel
®
8th/9th Generation Core™ i3 processors, Intel
®
Pentium™
and Celeron™ Processors (Coffee Lake)
* Refer to ASUS server AVL for the latest update
Core Logic Intel
®
C242 Chipset
Memory
Total Slots
4 (2-Channels)
Capacity
Maximum up to 128GB (UDIMM)
Memory Type
DDR4 2666 / 2400 ECC / non-ECC UDIMM
* Refer to ASUS server AVL for the latest update
Memory Size
32GB, 16GB, 8GB, 4GB (UDIMM)
* Refer to ASUS server AVL for the latest update
Expansion
Slots
Total PCI/PCI-X/
PCI-E/PIKE Slots
4
Slot Type
1 x PCI-E x16 (Gen3 x16 Link)
1 x PCI-E x8 (Gen3 x4 Link)
2 x PCI
Disk
Controller
SATA Controller
Intel
®
C242
6 x SATA 6Gb/s ports with 2 x M.2 (NGFF 22110/2280/2260/2242,
gray SATA port will be disables when M.2 is in SATA mode)*
Intel
®
RSTe (Windows & Linux)
(Supports software RAID 0, 1, 10 & 5)
* One supports both SATA 6Gb/s & PCI-E Gen3 x2 link, the other is
SATA 6Gb/s only.
SAS Controller
Optional:
ASUS PIKE II 3008-8i 8-port SAS 12G RAID card
Storage
Bays
I = internal
A or S will be hot-
swappable
3 x Internal 3.5” (or 2 x 2.5” optional cage) drive bays*
1 x Internal 2.5” drive bay
1 x Optional internal 5.25” to 3.5”/2.5” drive cage
2 x M.2 (NGFF 22110/2280/2260/2242)
* Supports only 1 drive when add-on card over 9.5” is installed on x16
link slot
Networking LAN
1 x Intel
®
I210-AT Gigabit LAN + 1 x Intel
®
I219-LM Gigabit LAN
Graphic VGA
Aspeed AST2510 64MB
Auxiliary Storage Device Bay
(Floppy / Optical Drive)
2 x 5.25” media bays
Options: No Device / DVD-RW / DVD ROM
(continued on the next page)

Asus TS100-E10-PI4 Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
LAN controller	Intel I210-AT, Intel I219LM
Audio chip	Realtek ALC887-VD2
Processor socket	LGA 1151 (Socket H4)
Motherboard chipset	Intel C242
Compatible processor series	Intel Celeron, Intel Core i3, Intel Pentium, Intel Xeon
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Maximum internal memory	128 GB
Supported memory clock speeds	2400, 2666 MHz
PCI slots	2
PCI Express x8 slots	1
PCI Express slots version	3.0
Chassis type	Full-Tower
Cooling type	-
Product type	Workstation barebone
Product color	Black, Metallic
LED indicators	HDD, Power, Reset
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of SATA III connectors	6
RAID levels	0, 1, 5, 10
Storage drive interface	M.2, PCI Express, Serial ATA
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD
On-board graphics card model	Aspeed AST2510
Power supply	500 W
AC input voltage	220 - 240 V
Power supply type	Internal power supply unit
AC input frequency	50 - 60 Hz
AC adapter output current	7 A
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	423 mm
Width	190 mm
Height	435 mm
