Disassembly Procedure
V1.0
2 - 28
2. Tear up the mylar and remove 3 screws from Touchpad.
Assembly notice:follow the reverse numbers to lock screws.
Screw tightening torque: 2.5±0.25kgf-cm
3. Take the touchpad away.
4. Remove touchpad mylar from touchpad.
Assembly Notice: Please assemble touchpad to top case and then paste the touchpad mylar.
SCREW M2*2.5L K B-NI
#1 NY
1
2
3
