Asus Z170M-E D3 User Manual

ASUS Z170M-E D3
1-3
1.2.4 Layout contents
1.3 Central Processing Unit (CPU)
ThismotherboardcomeswithasurfacemountLGA1151socketdesignedfor6thGeneration
Intel
®
Core™i7/i5/i3,Pentium
®
,andCeleron
®
processors.
Connectors/Jumpers/Slots/LED Page
1.
ATXpowerconnectors(24-pinEATXPWR,8-pinEATX12V)
1-17
2.
CPUandchassisfanconnectors(4-pinCPU_FAN,4-pinCHA_FAN1/2)
1-19
3.
Intel
®
LGA1151CPUsocket
1-3
4. DDR3DIMMslots 1-7
5. USB3.0connectors(20-1pinUSB3_12,USB3_34) 1-16
6. M.2Socket3 1-18
7. Intel
®
Z170SerialATA6.0Gb/sconnector(7-pinSATA6G_3~6)
1-20
8. Systempanelconnector(20-5pinPANEL) 1-21
9. StandbyPowerLED(SB_PWR) 1-22
10. TPMconnector(14-1pinTPM) 1-16
11. ClearRTCRAM(2-pinCLRTC)
1-12
12. USB2.0connectors(10-1pinUSB1112,USB1314) 1-15
13. LPTconnector(26-1pinLPT) 1-17
14. Serialportconnector(10-1pinCOM) 1-15
15. Frontpanelaudioconnector(10-1pinAAFP) 1-18
16. Digitalaudioconnector(4-1pinSPDIF_OUT) 1-19
Z170M-E D3 CPU socket LGA1151
Z170M-E D3
