Configuring fans manually
Select
Manual
from the list of proles to manually congure your fans’ operating speed.
To congure your fans:
1.
Select the fan that you want to congure and to view its current status.
2.
Click and drag the speed points to adjust the fans’ operating speed.
3.
Click
Apply
to save the changes then click
Exit (ESC)
.
Speed points
Click to manually
configure your fans
2-12
Chapter 2: Getting started
