ASUS Z170M-E D3
1-19
TheS/PDIFmoduleispurchasedseparately.
9. Digital audio connector (4-1 pin SPDIF_OUT)
ThisconnectorisforanadditionalSony/PhilipsDigitalInterface(S/PDIF)port.Connect
theS/PDIFOutmodulecabletothisconnector,theninstallthemoduletoaslot
opening at the back of the system chassis.
Z170M-E D3 Digital audio connector
SPDIF_OUT
+5V SPDIFOUT GND
PIN 1
Z170M-E D3
Donotforgettoconnectthefancablestothefanconnectors.Insufcientairowinside
thesystemmaydamagethemotherboardcomponents.Thesearenotjumpers!Donot
placejumpercapsonthefanconnectors!TheCPU_FANconnectorsupportsaCPUfanof
maximum1A(12W)fanpower.
Onlythe4-pinCPUfansupportstheASUSFanXpert2+feature.
10. CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN 1/2)
Connectthefancablestothefanconnectorsonthemotherboard,ensuringthatthe
black wire of each cable matches the ground pin of the connector
CHA_FAN1
CHA FAN PWM
CHA FAN IN
CHA FAN PWR
GND
A
CPU_FAN
CPU FAN PWM
CPU FAN IN
CPU FAN PWR
GND
BA
CHA_FAN2
GND CHA FAN PWR CHA FAN IN CHA FAN PWM
C
B
C
Z170M-E D3 Fan connectors
Z170M-E D3
