25
9.8 Flue gas exhaust system
The ue gas exhaust system and air supply system consists of:
- Flue gas pipe;
- Air supply pipe;
- Roof or wall terminal.
The ue gas exhaust system and air supply system must comply with:
The ue gas outlet and air supply installation must comply with the current regulation requirements. IG UP 10
and BS 715.
The ATAG iS boiler as described in this manual is NOT suitable for a combined ue system.
The appliance concentric connection diameter is 60/100 mm, to which the ue gas outlet and air supply
system can be tted, with or without elbow pieces. The maximum permissible pipe length is set out in Table
9.8.2.a.
For further information about the available components of the ue gas and air supply system we recommend
you consult the Flue system literature. Combinations with other brands or systems are, without written
permission from ATAG Heating, not permitted.
The ATAG ue gas system is meant, and designed, solely for the use on ATAG central heating boilers
adjusted to Nat gas or LPG. For this purpose the CE Certicate has been supplemented under the Gastec
nr: 0063CQ3634 The maximum ue gas temperatures are below 70°C (full load 80/60°C).
The proper operation may be adversely inuenced by changes of or adjustments to the correct set up.
Possible warranty claims will not be honoured if incorrect changes result in non compliance with the
installation manual or local rules and regulations.
P/A
Room sealed system Figure 9.8.a
P/A
P/A P/A
LEGEND:
P/A Polypropylen / Aluminium
Room sealed system
Boiler Class C
Permitted only
when the air
intake and the ue gas
outlet are in the same
pressure area.
