-45 kW range (ER S-2)
parameters units 30+ kW 37 kW 45 kW
Recoverable energy kW 22.5 27.8 33.8
Water flow l/Min 4.5 5.6 6.7
Temperature at inlet °C 20 20 20
Temperature at outlet °C 92 92 92
Pressure drop bar 0.004 0.005 0.007
37
+
-75 kW & VSD range (ER S-2)
parameters units 37+ kW
(VSD)
45+ kW
(VSD)
55 kW
(VSD)
75 kW
Recoverable energy kW 27.8 33.8 41.3 56.3
Water flow l/Min 5.6 6.7 8.3 11.4
Temperature at inlet °C 20 20 20 20
Temperature at outlet °C 92 92 91 91
Pressure drop bar 0.005 0.007 0.010 0.019
55
+
-90 kW & VSD range (ER S-3)
parameters units 55+ kW 75+ kW
(VSD)
90 kW
(VSD)
Recoverable energy kW 41.3 56.3 67.5
Water flow l/Min 8.3 11.4 13.6
Temperature at inlet °C 20 20 20
Temperature at outlet °C 91 91 91
Pressure drop bar 0.004 0.007 0.010
90
+
-180 kW & VSD range (ER S-4)
Parameters Units 90+ kW 110(+) kW
(VSD)
132(+) kW
(VSD)
160(+) kW
(VSD)
180 kW
(VSD)
Recoverable energy kW 67.5 82.5 99.0 120.0 135.0
Water flow l/min 13.5 16.6 20.0 24.2 27.2
Temperature at inlet ºC 20 20 20 20 20
Temperature at outlet ºC 91 91 91 91 91
Pressure drop bar 0.007 0.010 0.014 0.020 0.024
180
+
-315 kW range (ER S-5)
Parameters Units 200 kW 250 kW 315 kW
Recoverable energy kW 150.0 187.5 236.3
Water flow l/Min 30.2 37.8 47.6
Temperature at inlet °C 20 20 20
Temperature at outlet °C 91 91 91
Pressure drop bar 0.020 0.029 0.044
