(1) Next service
(2) Level
(3) Running hours
(4) Actual
In the example above, the A Service level is programmed at 4000 running hours, of which 0 hours have passed.
History
The History screen shows a list of all service actions done in the past, sorted by date. The date at the top is
the most recent service action. To see the details of a completed service action (e.g. Service level, Running
hours or Real time hours), use the Scroll keys to select the desired action and press the Enter key.
3.12 Modifying the setpoint
Control panel
(1) Scroll keys
(2) Enter key
(3) Escape key
Menu icon, Setpoint
Function
On compressors with a frequency converter driven main motor, it is possible to program two different
setpoints. This menu is also used to select the active setpoint.
Instruction book
2920 7104 10 43
