Atlas Copco GA 5 VSD MED User Manual

Oil capacity cu. ft. 0.18 0.18 0.18 0.18
Sound pressure level (according to ISO
2151 (2004))
dB(A) 66 66 66 66
Specific data for GA 15 VSD
Unit GA 15 VSD GA 15 VSD GA 15 VSD GA 15 VSD
Normal effective working pressure bar(e) 5.5 7 9.5 12.5
Normal effective working pressure psig 80 102 138 181
Maximum effective working pressure,
Workplace
bar(e) 7.5 7.5 10 13
Maximum effective working pressure,
Workplace
psig 109 109 145 189
Maximum motor shaft speed rpm 4075 4075 3640 2881
Minimum motor shaft speed rpm 1040 1040 1100 1100
Nominal motor power kW 15 15 15 15
Nominal motor power hp 20.1 20.1 20.1 20.1
Oil capacity l 5.2 5.2 5.2 5.2
Oil capacity US gal 1.37 1.37 1.37 1.37
Oil capacity Imp. gal 1.14 1.14 1.14 1.14
Oil capacity cu. ft. 0.18 0.18 0.18 0.18
Sound pressure level (according to ISO
2151 (2004))
dB(A) 69/3 69/3 69/3 69/3
9.5 Technical data Elektronikon® controller
General
Parameter Value
Supply voltage 24 V AC /16 VA 50/60Hz (+40%/-30%)
24 V DC/0.7 A
Type of protection IP54 (front)
IP21 (back)
Ambient and temperature
conditions
IEC60068-2
Temperature range
•
Operating
•
Storage
•
-10°C…..+60°C
•
-30°C…..+70°C
Permissible humidity Relative humidity 90%
No condensation
Noise emission IEC61000-6-3
Noise immunity IEC61000-6-2
Mounting Cabinet door
Instruction book
94 2920 7104 10
