Atlas Copco ga55+ User Manual

48
Instruction book
9096 3313 00
Procedure
Starting from the Main screen (see Main screen):
• Move the cursor to the action button Menu and press the enter key (2), following screen appears:
Text on figure
(1) Configuration
(2) Pressure Settings
(3) Mainscreen
• Using the scroll keys (1), move the cursor to the counters icon (see above, section Menu icon)
• Press the enter key (2), following screen appears:
Text on figure
(1) Counters
(2) Running hrs
(3) Loaded hrs
(4) Motor starts
(5) Module hrs
(6) Back
• The screen shows a list of all counters with their actual readings.

Atlas Copco ga55+ Specifications

General

Model	GA55+
Category	Air Compressor
Working Pressure	7.5 bar
Motor Power	55 kW
Noise Level	69 dB(A)
Cooling System	Air-cooled
Drive Type	Direct Drive
Free Air Delivery	10.2 m³/min
