Atlas Copco GA90 User Manual

132
Instruction book
9096 3313 00
11 Technical data
11.1 Readings on display
Display of the Elektronikon®
Important
The readings mentioned below are valid under the reference conditions (see section
Reference conditions and limitations).
Reference Reading
Air outlet pressure Modulates between programmed unloading and loading pressures.
Compressor element
outlet temperature
For air-cooled units: approx. 60 °C above cooling air inlet temperature For
water-cooled units: approx. 60 °C above cooling water inlet temperature.
Dewpoint temperature See section Compressor data.
Pressure difference over
oil separator
Below 1 bar.
Cooling water outlet
temperature
Below 50 °C.

Atlas Copco GA90 Specifications

General

Model	GA 90
Power	90 kW
Type	Rotary Screw Compressor
Max Working Pressure	13 bar
Cooling System	Air Cooled
Noise Level	72 dB(A)
