61
Instruction book
9096 3313 00
Text on figure
• Using the scroll keys (1), move the cursor to the info icon (see above, section Menu icon)
• Press the enter key (2), the Atlas Copco internet address appears on the screen.
3.15 Week timer menu
Control panel
Menu icon, week timer
Function
• To program time-based start/stop commands for the compressor
• To program time-based change-over commands for the net pressure band
• Four different week schemes can be programmed.
• A week cycle can be programmed, a week cycle is a sequence of 10 weeks. For each week in the
cycle, one of the four programmed week schemes can be chosen.
Procedure
Starting from the Main screen (see Main screen):
• Move the cursor to the action button Menu and press the enter key (2), following screen appears:
(1) Configuration
(2) Pressure Settings
(3) Mainscreen

Atlas Copco GA90 Specifications

General

Model	GA 90
Power	90 kW
Type	Rotary Screw Compressor
Max Working Pressure	13 bar
Cooling System	Air Cooled
Noise Level	72 dB(A)
