Atlas Copco Tensor User Manual

15
14
13
12
11
8
7
4
1
2
3
5
6
9
10
3
DISPLAY/KEY PAD
1. Display
2. OK LED
3. n x OK LED
4. Lock LED
5. NOK LED
6. Alarm LED
7. Graph LED
8. IRDA
9. Function button
10. AutoSet button
11. Plus button (+)
12. Question mark
button
13. Enter key button
14. Minus button (-)
15. Power
OK LED
Lights up after each tightening with
correct torque.
NOK LED
– Lights up af ter each tightening reaching
first target but not correct torque.
Question Mark 
– By pushing this button you can see:
❑ Drive program software version.
❑ Drive version (D302-Basic functionality,
D312-Advanced functionality).
❑ Drive size (DS4, DS7, DS9).
For further information check the DS Drive Manual.
–



Atlas Copco Tensor Specifications

General

Category	DC Drives
Brand	Atlas Copco
Name	Tensor
Output Power	Varies by model (Consult specific product documentation)
Input Voltage	Varies by model (Consult specific product documentation)
Output Voltage	Varies by model (Consult specific product documentation)
Communication Interfaces	Ethernet, Fieldbus
Enclosure Rating	IP20 (typical, may vary by model)
