Atlas Copco U190 PACE KD WUX User Manual

- 36 -
BASIC OPERATION OF THE MACHINE
The compressor can be controlled in 4 different
modes:
 Local Operation Mode: locally at the Operating
Panel,
 Remote Operation Mode: via remote switch
inputs located at the bottom of the Control panel,
 Automatic Operation Mode: via pressure sensor
data from the customer's installation,
 PC Operation Mode: with software running on a
PC.
In this section is described how to operate the
machine in Local Operation Mode at the Operation
Panel.
CONTROL PANEL
Reference Name
Power off / on switch
To switch the control panel on and off
Start button
Pressing this button will start the compressor.
Stop button
Pressing this button will stop the compressor in a controlled way.
