Atlas Copco XAHS 146 Dd S3B APP User Manual

- 22 -
ELECTRICAL SYSTEM
CIRCUIT DIAGRAM 9822 0028 02
XAHS 146, XATS 156, XAS 186
Tag Desc. 1 Desc. 2 Location Sheet/
Col.
B58 Pressure sensor DOC Engine 02/8
D1 Diode Machine 02/3
F1 Fuse Fuel pump 20A Machine 02/1
F2 Fuse ECU 30A Machine 02/1
G1 Battery Power Machine 02/1
G3 Alternator Charging Engine 02/3
K0 Relay Starter motor Engine 02/2
K2 Relay Preheater Machine 03/3
K3 Relay Fuel pump Machine 02/5
LS1 Level switch Coolant level Machine 04/5
LS4 Level switch Water in fuel level Machine 02/4
LT1 Level sensor Fuel level Machine 04/6
M1 Motor Starter Engine 02/2
M2 Pump Fuel Machine 04/1
PT1 Pressure sensor Regulating pressure Machine 04/1
Q2 Circuit breaker Mains 15A Machine 02/3
R2 Resistor Charging alternator Machine 02/3
R3 Resistor CAN Diagnostic Machine 02/10
R4 Resistor CAN Diagnostic Machine 02/10
R5 Resistor CAN Diagnostic Machine 02/9
R6 Resistor CAN ECU Machine 04/2
S1 Switch Battery cut-off Machine 04/7
S2 Switch Emergency stop Machine 04/9
Tag Desc. 1 Desc. 2 Location Sheet/
Col.
X1 Connector Control panel Machine 04/2
X10 Connector Cosmos control panel Optional 04/4
X11 Connector Cosmos Optional 04/4
X22 Connector Diagnostic Machine 02/10
X39 Connector Deutz Engine 02/8
Y1 Solenoid valve Load Machine 04/9
Wire size Colour code
aa = 0.75 mm
2
0 = black
a = 1 mm
2
1 = brown
b = 1.5 mm
2
2 = red
bx = 1.5 mm
2
NSGAFOÜ 3 = orange
c = 2.5 mm
2
4 = yellow
cx = 2.5 mm
2
NSGAFOÜ 5 = green
d = 4 mm
2
6 = blue
e = 6 mm
2
7 = purple
f = 10 mm
2
8 = grey
fx = 10 mm
2
NSGAFOÜ 9 = white
h = 25 mm
2
54 = green/yellow
l = 95 mm
2
mx = 120 mm
2
EPR-CSP to BS6195 4C
nx = 150 mm
2
EPR-CSP to BS6195 4C
