PERFORMANCE DATA
At reference conditions, if applicable, and at normal shaft speed, unless otherwise stated.
1)
Free Air Delivery (volume flow rate) is measured according to ISO 1217 ed.4 2009 annex D
Tolerance:
• +/- 5% 25 l/s (53 cfm) < FAD < 250 l/s (530 cfm)
• +/- 4% 250 l/s (530 cfm) < FAD
Designation
XAHS 146
XAHS 300
XATS 156
XATS 350
XAS 186
XAS 375
XAVS 166
XAVS 340
XAHS 186
XAHS 375
Engine shaft speed, normal and maximum r/min 2000 2030 2200 2100 2100
Engine shaft speed, compressor unloaded r/min 1700 1700 1700 1700 1700
Free air delivery
1)
standard l/s 145 156 188 158 176
cfm 307 330 398 335 373
with aftercooler l/s 139 150 181 154 170
cfm 294 318 384 326 360

Atlas Copco XAHS 146 Dd S3B APP Specifications

General

Brand	Atlas Copco
Model	XAHS 146 Dd S3B APP
Category	Air Compressor
Language	English
