- 15 -
Leading particulars
SAFETY PICTOGRAMS USED
QR CODE
The unit is equipped with a QR code label. You will
find the QR code next to the operating panel.
Scanning the code with your smartphone or tablet will
lead you to a website with additional information
about your compressor.
GENERAL DESCRIPTION
The compressors type XAHS 38 - XAHS 70 ranging
to XAS 88 - XAS 175 are silenced, single-stage, oil-
injected screw compressors, built for a nominal
effective working pressure of 7 bar (102 psi) to 12 bar
(175 psi) (see chapter Technical specifications).
The compressor is equipped with a PE canopy.
PE is very robust, can't corrode and will keep its shape
and color during the full lifetime of the machine. It is
fully recyclable to keep the environmental impact as
low as possible. Its low weight (below 750 kg) makes
it possible to tow it with a standard European driver's
license.
The canopy has openings at the shaped front and rear
end for the intake and outlet of cooling air. The
canopy is internally lined with sound-absorbing
material.
This symbol draws your attention to
dangerous situations. The operation
concerned may endanger persons and
cause injuries.
This symbol is followed by
supplementary information.
Some parts of this website may be
password protected.
Box_2-2.book Page 15 Friday, October 27, 2017 3:48 PM
