Atlas Copco XAHS 70 KD8 WUX User Manual

- 21 -
TOWING INSTRUCTIONS
Label on towbar, towing instructions Fixed towbar with support leg and brakes
For both non-adjustable - and adjustable towbar, the
towbar should be as level as possible and the
compressor and towing eye end in a level position.
Push the hand brake lever (3) completely downwards
and connect breakaway cable to the vehicle. Secure
jockey wheel (2) or support leg (1) in the highest
possible position.
Towing position of jockey wheel
Before towing the compressor, ensure
that the towing equipment of the vehicle
matches the towing eye or ball
connector, and ensure that the hood is
closed and locked properly.
(1)
(3)
(2) (2)
Box_2-2.book Page 21 Friday, October 27, 2017 3:48 PM

Atlas Copco XAHS 70 KD8 WUX Specifications

General

Brand	Atlas Copco
Model	XAHS 70 KD8 WUX
Category	Air Compressor
Language	English
