- 27 -
Operating instructions
PARKING, TOWING AND LIFTING
INSTRUCTIONS
Safety precautions
Attention:
PARKING INSTRUCTIONS
Non-adjustable towbar with standard support leg without
brakes
Adjustable towbar with jockey wheel and brakes
Parking position of jockey wheel
When parking a compressor, secure support leg (1) or
jockey wheel (2) to support the compressor in a level
position. Be sure that the jockey wheel (2) is blocked
by the blocking pin (4).
Apply parking brake by pulling parking brake handle
(3) upwards. Place the compressor as level as
possible; however, it can be operated temporarily in
an out-of-level position not exceeding 15°. If the
compressor is parked on sloping ground, immobilize
the compressor by placing wheel chocks (available as
option) in front of or behind the wheels.
The operator is expected to apply all
relevant safety precautions, including
those mentioned on the pages 7 - 13 of
this book.
Before putting the compressor in to use,
check the brake system as described in
section Brake (= option) adjustment.
After the first 100 km travel:
Check and retighten the wheel nuts and
towbar bolts to the specified torque. See
section Height adjustment and section
Torque values.
Check the brake adjustment. See section
Brake (= option) adjustment.
