• Push the Enter key; the low band setting becomes highlighted. Push the Enter key to modify the
on/off setting or use the arrow down key to modify the low setting.
• Push the Enter key to confirm the modification.
• Proceed to modify the high band setting.
6.18 Programmable settings
Service settings
Factory
setting
Service
Service level A hr 4000
Service level B hr 8000
Service level C hr 16000
Service level D hr 40000
Service level E hr 60000
Service level I hr 2000
Remark
A number of service operations are grouped (Level A, Level B, ...). Each level stands for a number of
service operations to be carried out at the programmed intervals. Consult your Atlas Copco Service Center.
Other programmable settings
Unit
Min.
(Pack
version)
Min.
(Full-
Feature
version)
Max.
Max. (with
Energy
Recovery)
Pressure regulation (UN)LOAD level
mbar
7 bar (60 Hz ) 4000 5000 7005 6505
7.5 bar (50 Hz) 4000 5500 7505 7005
8.6 bar (50 Hz) 4000 6500 8605 8105
8.6 bar (60 Hz) 4000 6500 8605 8105
10 bar (50 Hz) 7000 7500 10005 9505
10.4 bar (60 Hz) 7000 7500 10405 9905
13 bar (50 Hz) 7000 9500 13005 12505
13 bar (60 Hz) 7000 9500 13005 12505
=>converted (m)bar-psi values psi
* 101.5 psi (60 Hz) 58.0 72.5 101.6 94,3
* 108.7 psi (50 Hz) 58.0 79.8 108.9 101.6
* 125 psi (50 Hz) 58.0 94.3 124.8 117.6
Instruction book
164 2920 1815 04
