5.4 Scroll keys
Control panel
The keys (1) allow the operator to scroll through the display.
As long as a downwards pointing arrow is shown at the utmost right position of the display, the scroll key
with the same symbol can be used to see the next item.
As long as an upwards pointing arrow is shown at the utmost right position of the display, the scroll key
with the same symbol can be used to see the previous item.
When the scroll key is kept pressed, the scrolling is continued.
5.5 Emergency stop button
Control panel
In case of emergency, press button (S2) to stop the compressor immediately.
At the occurrence of an emergency stop, the compressor element is stopped immediately and the solenoid
valve will be deactivated by Elektronikon ® regulator. No unload status is reached. The check valve
prevents oil flow back from reversed rotation of the compressor element.
Instruction book
2920 1815 04 81
