OWNER'S MANUAL
AA35 MIXER AMPLIFIER
18
SIGNAL PATH BLOCK


INPUT XFMR
MAN. MUTE OVERRIDE
LIMITER
LINE OUT
PWR AMP 35W
PEAK LED
CHANNEL 1
ATLAS SOUND
MODEL AA35
© 2006
MIX BUS AMP
12
3
4
5
67
MUTE RECEIVE
MUTE
1W @ 8Ω
1V @ 600Ω
IN 3 LEVEL
MUTE
CHANNEL 2
CHANNEL 3
PHANTOM
AMP IN PRE OUT
IN 2 LEVEL
IN 1 LEVEL
ZONE 1 OUTPUT
70.7V
25V
8Ω
COM
SIGNAL LED
A
B
ZONE 2 OUTPUT
BASS TREBLE
ZONE 2 LEVEL
FILTER
OPTIONAL
JUMPER
POWER
+
FUSE
POWER SW
FUSE
BREAKER
AC120V AC
AC120V 60Hz
POWER TRANS
Uncontrolled, For Reference Only
8

Atlas AA35 Specifications

General

Package weight	4630 g
Amplifier class	-
Frequency range	50 - 20000 Hz
Output impedance	8 Ω
Audio output channels	3.0 channels
Peak power per channel	35 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
Purpose	Performance/stage
Product color	Black
Volume control	Rotary
Bass adjustment	Yes
Channels quantity	3 channels
Connectivity technology	Wired
AC input voltage	110 - 120 V
Power source type	AC
Speakers connectivity type	Phoenix / RCA

Weight and Dimensions

Depth	276 mm
Width	210 mm
Height	93 mm
