To install the MP-124 in a 19-inch rack:
1. Remove the two screws located on one side of the MP-124 (nearest the front panel).
2. Insert the peg on one of the brackets into the third air vent down on the column of air
vents nearest the front panel.
3. Swivel the bracket until the holes in the bracket align with the two empty screw holes
on the MP-124.
4. Use the supplied screws to attach the bracket to the side of the MP-124.
5. Repeat steps 1 through 4 to attach the second bracket to the other side of the MP-124.
6. Position the MP-124 in the rack and line up the bracket holes with the rack frame
holes.
7. Use four standard rack screws (not supplied) to attach the MP-124 to the rack.
2.2.4 Cabling the MP-124
This section describes the MP-124 cabling procedures:
Grounding (earthing) MP-124 (refer to 'Grounding the MP-124' 26 on page ).
Connecting to the Ethernet network (refer to 'Connecting MP-124 to the Ethernet
Network' 28 on page ).
Connecting to FXS analog lines (refer to 'Connecting MP-124 to FXS Interface'
29
on
page ).
Serial connection to a computer (refer to 'Connecting MP-124 RS-232 Port to a PC'
31
on
page ).
Connecting to the power supply (refer to 'Connecting MP-124 to Power' 32 on page ).
Once you have completed the above hardware installation steps and after powering-up the
MP-124, the Ready and LAN LEDs on the front panel light up green (after a self-testing
period of about a minute). Any malfunction in the startup procedure changes the Ready
LED to red (for details on the MP-124 LEDs, refer to 'Monitoring Front-Panel LEDs'
55
on page
). Once you have cabled the device, you can begin configuring the device (refer to
'Configuring the Device' 35 on page ).
