AudioCodes MediaPack MP-124 Installation Manual

Installation Manual 42 Document #: LTRT-59811
MediaPack Series
3.2 Configuring Basic SIP Parameters
Once you have completed the previous sections, you are ready to start configuring the
device using the Web interface. For information on how to fully configure the device, refer to
the device's User’s Manuals.
Tip: Once the device is configured, backup your settings by saving the
configuration (ini) file to your PC. This saved file can later be used, if
necessary, to restore configuration settings (refer to 'Backing Up and
Restoring Configuration' 47 on page ).
 To configure basic SIP parameters:
1. Access the Web interface.
2. Select the voice coders used by the device that best suits your VoIP network in the
'Coders Table' page (Configuration tab > Protocol Configuration menu > Coders
And Protocol Definitions submenu > Coders
3. When operating with a Proxy server, perform the following (otherwise, skip to Step 4):
).
a. In the 'Proxy & Registration' page (Configuration tab > Protocol Configuration
menu > Proxies, Registration, IP Groups submenu > Proxy & Registration
♦ Set the ‘Use Default Proxy’ field to "Yes".
):
♦ (Optional) In the ‘Proxy Name’ field, enter the Proxy's name. The Proxy
name replaces the Proxy IP address in all SIP messages. This means that
messages are still sent to the physical Proxy IP address, but the SIP URI
contains the Proxy name instead.
♦ To enable the device to register to a Proxy/Registrar server (at power up and
every user-defined interval - ‘Registration Time’ parameter), set the ‘Enable
Registration’ parameter to "Enable".
b. In the 'Proxy Sets Table' page (Configuration tab > Protocol Configuration
menu > Proxies, Registration, IP Groups submenu > Proxy Sets Table
4.
), define
the IP address(s) of the Proxy server(s). When no Proxy is used, the internal
routing table is used to route the calls.
5. If a Proxy server is not implemented, map outgoing calls to IP addresses in the
Enable the device's endpoints in the 'Endpoint Phone Number Table' page
(Configuration tab > Protocol Configuration menu > Endpoint Number submenu >
Endpoint Phone Number).
‘Outbound IP Routing Table’ page (Configuration tab > Protocol Configuration
menu > Routing Tables submenu > Tel to IP Routing
6. Save your settings to the flash memory and reset the device (refer to '
).
Saving and
Resetting the Device' 44 on page ).
